The MANET3622-W is a compact and portable airborne radio with HD and stable image quality. It adopts the current leading OFDM modulation technology, allowing for capturing high-quality images in high-speed motion and real-time transmission in non-line-of-sight (NLOS) conditions. Encryption is applied to the images and data during transmission, supporting a transmission rate of 30Mbps. It is well-suited for long-term and high-data-flow wireless transmission applications, such as UAVs, USVs, and robots.
* Supports 3 bands (800MHz/1.4GHz/2.4GHz)
* IP transparent data transmission
* Compact size and light weight
* Rugged aluminum alloy housing
* Low power consumption
* With TTL and RJ45 port
| Model |
MANET3622-W |
Brand |
LINKAV |
| RF Parameters |
Frequency |
800MHz/1.4GHz /2.4GHz |
| Bandwidth |
1.4MHz/3MHz/5MHz/10MHz/20MHz |
| RF Channel |
1T2R |
| Network Parameters |
Network Mode |
One-to-one and one-to-many |
| Data Rate |
30Mbps(Max) |
| Encryption |
ZUC/SNOW3G/AES Optional |
Physical/
Environment |
Dimensions |
103.5*61.5*22mm |
| Weight |
142g |
| Electronic Parameters |
Power Supply |
DC12V |
| Other |
Data Interface |
RJ45*2,TTL*3 |
- Audio Interface
- RA232 Interface*3
- RJ45 Interface-1
- RJ45 Interface-2
- Power Input Interface
- Link Status Indicator - When the device works as an access node, if the connection with the central node is normal, the indicator will flash. When the device works as a central node, this indicator will be always on.
- Signal Indicator
- Power Indicator
- RF Antenna-2
- RF Antenna-1
